1989-2001 Honda CR500 Direct Bolt-On Performance Cylinder
Sale price
$1,199.00
Shipping calculated at checkout
The wait is almost over. This is exactly what the big bore community has been needing. Stop paying huge amounts of money for worn-out used cylinders that require extensive repair work, or shelling out a fortune for NOS units that still leave you stuck with factory stock performance.
Exclusive to Two-Strokes Only, this is the very first entirely new, direct-replacement stock bore cylinder of its kind to hit the CR500 market. We kept the proven characteristics of the original Honda design and strategically modernized the rest to unleash its true potential. No hacking, no case grinding, no headaches—just improved performance and unquestionable reliability in a true bolt-on package.
Whether you are rebuilding a blown top end or looking for the ultimate big-bore upgrade, this cylinder delivers modernized airflow and improved reliability without the need for extensive porting work.
What's Included & Optional Upgrades
Included in the box:
1. All-New CR500 Replacement Cylinder (STD 89 mm Bore)
2. Top end gasket set
Optional Add-Ons (Select from the drop-down menu):
- Piston Kit: Complete drop-in piston kit ready for installation.
- TSO Billet Cylinder Head: Maximize cooling and performance with our custom billet head.
- TSO Billet Reed Spacer: Optimize intake tract volume and throttle response.
- TSO Billet Exhaust Flange: A heavy-duty, leak-free upgrade over the stock cast flange.
Key Features
- Strategic Porting Evolution: We kept what actually worked from the original factory porting and made critical improvements where they were needed most. The result is an incredibly reliable, highly versatile cylinder that puts out more power than any hand-ported OEM unit on the market, while retaining a good useable powerband.
- Improved Exhaust & Thermal Management: Built around an improved single bridged exhaust port, this design maximizes flow while offering superior piston and ring support. We also engineered improved cooling at the top of the exhaust port duct to relieve thermal stress on the bridge, actively preventing the cracking commonly seen in bridged all-aluminum cylinders like the CR250.
- Rugged Construction: Cast from high-quality aluminum and finished with a low-friction Nikasil plated bore for unmatched heat dissipation, oil retention, and maximum longevity.
- True Direct Bolt-On: Drops right onto your factory bottom end. Zero crazy case modifications, machining, or bike alterations are required. Bolt it down and ride.
- Universal Compatibility: Build it your way. This unit is 100% compatible with all original (OEM) and aftermarket reeds, pipe flanges, cylinder heads, pistons, and top-end gaskets.
Technical Specifications
| Feature | Specification |
| Fitment | 1989–2001 Honda CR500 |
| Bore Size | 89.00mm |
| Material | All-Aluminum Cast |
| Bore Coating | Nikasil Plated |
| Porting Style | Optimized Factory-Plus |
| Exhaust Layout | Improved Single Bridged |
| Thermal Management | Upgraded Exhaust Duct Cooling |
| Modifications Required | None (Direct Bolt-On) |
| Compatibility |
Accepts all OEM & Aftermarket Top-End Components, replaces Honda 12100-ML3-680 DESIGNED TO WORK WITH WOSSNER AND WISECO FORGED PISTONS Wiseco: 871M08900 Wossner: 8229DA |
