Billet KIPS Resonator Cover (+10mm High-Volume) | Fits 1995-2006 Kawasaki KDX200 & KDX220
Shipping calculated at checkout
Smooth out the factory mid-range power dip and optimize the exhaust wave dynamics of your Kawasaki two-stroke with the Two-Strokes Only +10mm High-Volume Billet KIPS Resonator Cover. Engineered specifically for the 1995-2006 H-series Kawasaki KDX200 and KDX220, this component replaces the restrictive stock chamber plate with an upgraded, CNC-machined unit that precisely increases internal resonator volume.
The expanded volume lowers the resonant frequency of the power-valve circuit, effectively broadening the usable powerband and enhancing tractability right as the sub-ports open. Crafted from aerospace-grade aluminum and hard-anodized for ultimate durability, this one-piece replacement cover features integrated external cooling fins to shed heat efficiently while eliminating the structural drawbacks of using separate spacer plates.
Vehicle Fitment
| Make | Model | Year Range | Specific Years |
| Kawasaki | KDX200 / KDX220 | 1995–2006 | 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006 |
Kit Contents:
- +10mm High-Volume Billet Resonator Cover
- Precision-Matched Mounting Hardware
TSO Tip
When installing your high-volume resonator cover, ensure the cylinder mating surface is completely free of old gasket residue. Use a high-temperature gasket or a light application of ThreeBond 1211 to guarantee an airtight seal, and always cycle the KIPS linkage manually after torque-down to ensure no internal binding before firing the engine.
Compatibility
Fetching compatibility details...
| Year | Make | Model |
|---|---|---|
